The 58-C0215 Digital Pull-Off Tester is a portable instrument designed to measure the bond strength between concrete layers and the adhesion strength of coatings, plasters, renders, and repair materials. Its high-accuracy load cell and digital display provide reliable and repeatable pull-off test results for both laboratory and on-site applications.
Product: Pull-Off Tester
Pull-Off Tester
Maximum load capacity: 16 kN
Suitable for bond strength and adhesion testing
Wide measuring range for various construction materials
58-C0215
High-accuracy load cell
Resolution of 1 N
Accuracy better than ±1%
Graphic indication of applied load rate
EN 1015-12
EN 1348
EN 1542
EN 13963
EN 14496
EN 12004-2
ISO 13007-2
ISO 4624
ASTM D4541
ASTM C1583
ASTM D7234
EN 14891
Concrete repair bond testing
Coating adhesion testing
Plaster and render strength evaluation
Tile adhesive testing
Surface treatment quality assessment
Portable and lightweight design
High-resolution digital display
Integrated load cell
Battery-operated with AC adapter
Graphic load-rate indication
Serial port for PC connection
Ram position indicator for brittle material assessment
Supplied with traceable calibration certificate
Load Capacity: 16 kN
Working Range: 0.25 – 16 kN
Resolution: 1 N
Accuracy: Better than ±1%
Power Supply: 9V Battery
AC Adapter: 110–240V, 50/60Hz
Dimensions: 340 × 240 × 250 mm
Weight (Tester): 3.3 kg
Weight (With Case): 5 kg
